1. Advanced s-tube valve is adopted to meet the delivery of concrete;
2. The glasses plate and cutting ing are made of high hardness and wear resisting allay material, with longer service life;
3. Import main oil pump with high output pressure can meet high-rise buildings and distance transportation requirements
4. The hydraulic oil is cooled by air cooling system, which has good cooling effect and is easy to use;
| Model | HW20-22 |
| Power | 22kw |
| Voltage | 380V |
| Vertical delivery distance | 50m |
| Horizontal delivery distance | 80m |
| Output | 12m3/h |
| Max.Aggregate size | 20mm |
| Outlet diameter | 120mm |
| Cylinder stroke | 650mm |
| Pipe diameter | 100mm |
| Dimension | 2100*780*1200mm |
| Weight | 900kg |
